Palit GeForce GTX 1080 Ti HOF Limited Edition Announced: 1.75 GHz and Onboard LCD
Palit Microsystems plans to release a new factory-overclocked limited edition graphics adapter based on NVIDIA’s GeForce GTX 1080 Ti GPU under its GALAX and KFA2 brands. The card was developed from scratch and will be among the highest-performing video cards in the industry due to a rather extreme GPU frequency. It also comes with exclusive features that will further push it up on price.
The GeForce GTX 1080 Ti HOF Limited Edition graphics adapter from GALAX and KFA2 are based on NVIDIA’s GP102 GPU, clocked at 1645/1759 MHz (base/boost) and suses a custom 12-layer PCB developed by Palit. The add-in-board (AIB) features a 12+3-phase VRM and three 8-pin PCIe power connectors in a bid to guarantee stable operation of the GPU at significantly increased clock rates (165/177 MHz higher than NVIDIA’s recommendations) and enable further headroom for overclocking.
To cool down the GPU and memory, Palit uses a special cooling system that relies on a huge heatsink with five thick heatpipes as well as three fans. As an added bonus, the cooling system is equipped with an LCD screen that displays current GPU and memory frequencies, the GPU temperature, the GPU voltage and other important information. Since the cooler is very large, it takes three slots, meaning multi-GPU system builds with this card more complicated. Traditionally, large cooling solutions are equipped with a backplate and the cooler on the GeForce GTX 1080 Ti HOF Limited Edition is not an exception. As for outputs, the graphics adapter comes with three DisplayPort 1.4 headers, one HDMI 2.0b and one DVI-D.
With its factory overclocked GPU, the GeForce GTX 1080 Ti HOF Limited Edition from GALAX and KFA2 is going to be one of the highest-performing gaming graphics cards around. In fact, single precision compute performance of the AIB will be between 11.79 and 12.6 TFLOPS (depending on exact frequency), which is higher than that of NVIDIA’s Titan X and Titan Xp. The latter still have advantages when it comes to ROP count and memory bandwidth, but in at least certain cases the GTX 1080 Ti HOF Limited Edition is going to be faster.
| NVIDIA GPU Specification Comparison | |||||||
| NVIDIA Titan Xp | GALAX/KFA2 GeForce GTX 1080 Ti HOF Limited Edition |
NVIDIA GeForce GTX 1080 Ti |
NVIDIA Titan X (Pascal) |
NVIDIA GeForce GTX Titan X (Maxwell) |
|||
| CUDA Cores | 3840 | 3584 | 3584 | 3072 | |||
| Texture Units | 240 | 224 | 224 | 192 | |||
| ROPs | 96 | 88 | 96 | 96 | |||
| Core Clock | 1481 MHz? | 1645 MHz | 1481 MHz | 1417 MHz | 1000 MHz | ||
| Boost Clock | 1582 MHz | 1759 MHz | 1582 MHz | 1531 MHz | 1075 MHz | ||
| TFLOPs (FMA) | 12.1 TFLOPs | 12.6 TFLOPs | 11.3 TFLOPs | 11 TFLOPs | 6.1 TFLOPs | ||
| Memory Clock | 11.4 GT/s GDDR5X | 11 GT/s GDDR5X |
10 GT/s GDDR5X | 7 GT/s GDDR5 | |||
| Memory Bus Width | 384-bit | 352-bit | 384-bit | 384-bit | |||
| RAM | 12 GB | 11 GB | 12 GB | 12 GB | |||
| RAM Bandwidth | 547.2 GB/s | 484 GB/s | 480 GB/s | 336 GB/s | |||
| FP64 | 1/32 | ||||||
| FP16 (Native) | 1/64 | N/A | |||||
| INT8 | 4:1 | N/A | |||||
| TDP | 250W | 250W++ | 250W | 250W | 250W | ||
| GPU | GP102 | GM200 | |||||
| Transistor Count | 12B | 8B | |||||
| Die Size | 471mm2 | 601mm2 | |||||
| Manufacturing Process | TSMC 16nm | TSMC 28nm | |||||
| Launch Date | 04/06/2017 | ~05/2017 | 03/10/2017 | 08/02/2016 | 03/17/2015 | ||
| Launch Price | $1200 | ~$1200 | $699 | $1200 | $999 | ||
Meanwhile, pricing of the GALAX/KFA2 GeForce GTX 1080 Ti HOF Limited Edition will match pricing of the two aforementioned cards that are sold exclusively by NVIDIA for $1200. Overclockers UK offers to pre-order the card from KFA2 for £949.99 (with ETA in late May), which equals to $1227. It is noteworthy that in the UK the card will be called the KFA2 GeForce GTX 1080 Ti HOF 8 Pack Edition, after professional overclocker 8 Pack who works for Overclockers.
